Bandeja semi automática del huevo 1000pc/H que hace la máquina
| modelo | SL-3*1 |
| producción | 1000-1500 piezas/h |
| consumo de papel | 120 kilos por hora |
| Consumo de agua | 300kg/h |
| energía utilizada | 32kW/h |
| Obrero | 3-4 |
| materia prima | papel de desecho |
Ahora puede solicitar detalles técnicos a nuestros jefes de proyecto
The semi-automatic egg tray making machine is a machine used to produce egg trays. This machine can use waste paper products to be processed into egg trays. This egg tray machine is a semi-automatic egg tray machine because customers who buy this type of egg tray machine generally dry it naturally. The main function of this egg tray machine is the forming of egg trays. The complete production line also includes egg tray pulping, egg tray hot pressing, and egg tray packaging machines.
Introduction of egg tray making machine
This 1000pc/h egg tray machine is also called a 3*1 type egg tray machine. The output of the machine is relatively small, and it can produce 1000 pieces per hour. It is suitable for a small family workshop production. Small egg tray machines belong to small output production. You can use the drying method of natural drying, which can reduce the cost. However, the local weather conditions need to be considered, so the drying time is uncertain. If the local weather temperature is not so high, you can also choose a dryer to dry the egg tray, and the production efficiency is higher
Egg tray production machine parameters
| modelo | producción | consumo de papel | Consumo de agua | energía utilizada | Obrero |
| SL-3*1 | 1000-1500 piezas/h | 120 kilos por hora | 300kg/h | 32kW/h | 3-4 |
Staff arrangement of making egg tray
After the processing test, it was found that the number of workers employed for the egg tray was very small. The egg tray product line requires 4 people, namely 1 person in the pulping area, 1 person in the forming area, 1 person for packing after stacking, and 1 person for moving the warehouse. , a total of 4 people/class. Because the degree of automation of the machine is relatively high, it is only necessary to control the machine.
Semi-automatic egg tray making machine advantages
- La máquina para fabricar bandejas de huevos adopta una caja de cambios de alta precisión, que tiene una indexación precisa, un funcionamiento estable y poco ruido.
- Utilizando un sistema de control automático PLC, un sistema automático de conteo de pilas, un alto grado de automatización, ahorrando costos de mano de obra, el tanque de pulpa de la máquina de bandejas de huevos y el escudo están hechos de acero inoxidable, resistencia a la corrosión y larga vida útil.
- Con ingenieros de diseño de moldes especializados y talleres de fabricación de moldes, podemos diseñar y fabricar rápidamente diversos moldes para envases industriales y otros moldes especiales, y brindar servicios personalizados.
Egg tray making machine mold replacement
The mold of the egg tray machine can be replaced to produce different types of products, such as egg boxes, wine trays, fruit trays, and other products, mainly through the replacement of molds. For the production of egg trays, a tray can hold 12, 24, or 36 eggs, all of which can be processed.
